Worm Gear Rotary Table - AR Ø500
Smooth seamless transmission with high reduction ratios for precision loads.
HR-500R
HR-500R Product Specifications
| Item | Data |
|---|---|
| Application | Vertical or Horizontal |
| Installation Mode | Add-on |
| Table diameter(mm) | Ø500 |
| Inner diameter of mandrel sleeve(mm) | Ø220H7 |
| Diameter of center through hole(mm) | Ø220 |
| Center height (Vertical)(mm) | 310 |
| Table height (Horizontal)(mm) | 290 |
| Table T-slot width(mm) | 18H7 |
| Guide block width(mm) | 18h7 |
| Transmission Mechanisms | Worm & Worm Gear |
