Multi-Spindle Coupled Series

The Multi-Spindle Coupled Series is a 7-station precision CNC indexing system. Multiple spindle units are mechanically linked through a drive coupling. When the drive indexes, all coupled spindle positions rotate to the angular position simultaneously. This means multiple workpieces are indexed and presented to the cutting tool at the time in every cycle. This maximises the use of every machine cycle and delivers consistent angular positioning across all stations.

The output improvement comes directly from multi-station machining. By indexing and machining one workpiece at a time on a single rotary table, the Multi-Spindle Coupled Series allows several workpieces to be indexed and machined in parallel within the same CNC cycle. Depending on the spindle count configuration, this can multiply output by two, four or more times compared to a single-station rotary table setup. This is without requiring floor space, additional operators or additional CNC machine time.

The TJR Multi-Spindle Coupled Series is best suited to medium-sized precision components. These are produced in volumes and require consistent angular indexing as part of the machining process. Examples include transmission components, hydraulic valve bodies, pump housings, medical device components, electronic housing parts and small aerospace fittings. The system is particularly effective where multiple identical features such as holes, slots or faces must be machined at defined positions on every part in a batch.

Because all spindle positions are driven through the mechanical coupling, every station indexes to exactly the same angular position simultaneously. There is no angular error accumulating from station to station. The indexing accuracy of the TJR Multi-Spindle Coupled Series is governed by the precision standards of TJR's individual rotary table units. This ensures that every part across every station is machined to the positional accuracy in every cycle. SPT Engineering can provide the angular accuracy and repeatability data for each Multi Spindle configuration.

Yes. The TJR Multi-Spindle Coupled Series is well-suited to integration into automated production cells. These include those with loading and unloading pallet systems and automated quality inspection. The synchronised indexing drive simplifies the automation interface. This is because a single indexing command controls all stations simultaneously. SPT Engineering can advise on integration requirements. Help coordinate the interface between the TJR Multi-Spindle system and your specific automation setup.

SPT Engineering supports companies by giving them TJR Multi-Spindle Coupled Series systems made for synchronised work and high-production CNC jobs. We are a TJR Rotary Table distributor. We give people reliable Multi Spindle Rotary Table and CNC Coupled Rotary Table solutions made for factory needs. Our team helps companies make their work better, more efficient and precise through advice and dependable technical help.
