Hirth Coupling Index Table - HI Ø320
Sub-arcsecond angular precision for demanding multi-face machining operations.
HHI-320x320F
HHI-320x320F Product Specifications
| Item | Data |
|---|---|
| Application | Horizontal |
| Installation Mode | Add-on |
| Table diameter(mm) | □320x320 |
| Diameter of center through hole(mm) | Ø50x27deep |
| Table height (Horizontal)(mm) | 240 |
| Guide block width(mm) | 18h7 |
| Transmission Mechanisms | Worm & Worm Gear |
| Min. increment(deg.) | 1 or 5 |
| Indexing precision(sec.) | ±5 |
| Repeatability(sec.) | ±1 |
