- TJR Torque Motor Rotary Table - AD Ø170
TJR Torque Motor Rotary Table - AD Ø170
Direct-drive power with no mechanical wear and maximum torque at low speed.
AD-170
AD-170 Product Specifications
| Item | Data |
|---|---|
| Application | Vertical |
| Installation Mode | Add-on |
| Table diameter(mm) | Ø170 |
| Inner diameter of mandrel sleeve(mm) | Ø40H7 |
| Diameter of center through hole(mm) | Ø40 |
| Table height (Horizontal)(mm) | 135 |
| Table T-slot width(mm) | 12H7 |
| Guide block width(mm) | 18h7 |
| Transmission Mechanisms | Direct Drive |
| Min. increment(deg.) | 0.001 |
Frequently Asked Questions
The TJR AD-170 is a torque motor rotary table for CNC machines. It is mainly used as a 4th axis for accurate rotary machining.
The AD-170 has a 170 mm table diameter. Its compact size makes it a good choice for CNC machines with limited space.
Yes. The AD-170 is designed for 4th-axis CNC machining. It helps rotate the workpiece so you can machine different sides easily.
The AD-170 uses a direct-drive torque motor. It does not use a worm gear or other reduction gears.
The AD-170 offers precise rotary positioning. It has a minimum increment of 0.001 degrees and repeatability of 4 seconds.
The AD-170 has a maximum speed of 200 rpm. This allows fast and smooth rotary movement during CNC machining.
The AD-170 can handle up to 30 kg in vertical use. With a support table, it can handle up to 70 kg.
The AD-170 has a rated cutting torque of 50 Nm. Its maximum cutting torque is 183 Nm.
A direct-drive rotary table provides fast movement and accurate positioning. It also has fewer mechanical parts, which can help reduce wear and maintenance.
The AD-170 is a compact and accurate CNC rotary table for 4th-axis machining. It offers high speed, good positioning accuracy, and strong cutting torque for precision machining.
