TJR Torque Motor Rotary Table - AD Ø650
Direct-drive power with no mechanical wear and maximum torque at low speed.
iHHD-650
iHHD-650 Product Specifications
| Item | Data |
|---|---|
| Application | Horizontal |
| Installation Mode | Integrated |
| Table diameter(mm) | Ø650 |
| Inner diameter of mandrel sleeve(mm) | Ø50 x 30deep |
| Table T-slot width(mm) | 18H7 |
| Transmission Mechanisms | Direct Drive |
| Min. increment(deg.) | 0.001 |
| Cooling System | Oil Cooling |
| Indexing precision(sec.) | 20 |
| Repeatability(sec.) | 4 |
Frequently Asked Questions
The TJR iHHD-650 is a direct-drive torque motor rotary table for CNC machines. It is designed for horizontal machining and heavy-duty applications.
The iHHD-650 has a 650 mm table diameter. It also has a 50 mm inner diameter with a 30 mm deep mandrel sleeve.
Yes. The iHHD-650 can be used as a 4th-axis rotary table for CNC machining. It helps rotate the workpiece for machining different sides.
The iHHD-650 uses a direct-drive system with a DD torque motor. It does not use a mechanical reduction gear.
The iHHD-650 has a minimum increment of 0.001 degrees. It offers 20-second indexing precision and 4-second repeatability.
The iHHD-650 has a rated speed of 80 rpm and a maximum speed of 210 rpm. This provides fast and smooth rotary movement.
The iHHD-650 can handle a maximum workpiece load of 400 kg in horizontal use.
The iHHD-650 has a rated cutting torque of 554 Nm and a maximum cutting torque of 741 Nm. This makes it suitable for demanding machining work.
The iHHD-650 uses an oil cooling system. Oil cooling helps maintain stable performance during heavy machining.
The iHHD-650 is a large and strong CNC torque motor rotary table for horizontal machining. It offers a 650 mm table, direct drive, up to 210 rpm speed, 400 kg workpiece capacity, and up to 741 Nm cutting torque.
